Screen size
5.0 inches
Camera pixel count
8 megapixels
Battery capacity
2,300mAh
Maximum download speed
112.5Mbps
Android™ 6.0
One Seg
waterproof
Wallet
It has a shock-resistant structure. Even if it is dropped, the display is unlikely to shatter, making it safe for use in sports.
The waterproof design means you can use your smartphone even when it gets wet, whether it's in a sudden rain shower, while cooking, or when enjoying videos in the bath, so you can use it with peace of mind.
You can rest assured even when you are concerned about dust and dirt, such as when gardening, doing outdoor leisure or sports.
The touch panel display can be used even when the screen or your hands are wet, so you can enjoy your bath time however you like, by browsing the internet, watching videos, or reading.
You can also operate the device comfortably while wearing gloves when BBQing or gardening, motorcycle gloves, or winter gloves.
Not only can you enjoy beautiful photos and videos, but it also displays small text clearly, making browsing the Internet a breeze.
The simple home screen clearly displays the necessary information and frequently used functions, allowing even first-time smartphone users to operate the device with ease.
Text input is possible in the same way as with a mobile phone, so even if this is your first smartphone, you can operate it just like a mobile phone that you are familiar with.
Equipped with a highly sensitive sensor, it can take bright, clear photos even in dimly lit places.
Send and receive contacts and images with simple operations. Easily share information with family and friends.
It can be used for up to three days *1 without needing to be charged, so you can use it without worry even when you are away for long periods of time, such as on business trips or traveling.
By turning on Eco mode, you can reduce battery consumption and extend standby time. Furthermore, by using the timer setting, you can freely set the time to turn Eco mode on/off according to the rhythm of your life.
It includes high-frequency sound components that were cut in conventional audio, resulting in clear, easy-to-hear calls without muffled sound.
You can choose between "soft" and "clear" sound quality depending on the situation. You can also adjust it during a call.
| size Width x height x thickness of main body excluding protrusions
|
約W72×H142×D10.8mm |
|---|---|
| Weight Weight with battery pack installed
|
約138g |
| Continuous talk time *1
Talk time when signal reception is normal
|
[3G] 1190 minutes [LTE] 880 minutes [GSM] 570 minutes |
| Continuous standby time *1
Standby time when signal reception is normal
|
[AXGP] Approx. 600 hours [LTE] Approx. 650 hours [3G] Approx. 860 hours |
| Battery capacity Battery capacity, which is an indication of continuous usable time, etc.
|
2,300mAh |
| Charging time Approximate time required to fully charge the battery from a completely empty state
|
Approximately 180 minutes (microUSB 1.0A AC adapter) Approximately 140 minutes (AC adapter compatible with Quick Charge 2.0) *Although it does not support Quick Charge 2.0, charging is possible. |
| Platform OS and version installed
|
Android™ 6.0 |
| CPU Data processing speed and number of processor cores
|
MSM8916 1.2GHz (quad core) |
| ROM/RAM capacity The capacity of the built-in memory installed in the device
|
8GB / 2GB |
| Supported external memory / Maximum supported capacity *2
Types and capacities of memory cards that can store images, videos, music files, etc.
|
microSDXC™ / Maximum 200GB |
| Data communication method Supported communication standards or methods
|
FDD-LTE / AXGP / 3G |
|---|---|
| Maximum communication speed (for "4G") *3
Maximum data communication speed in "4G" area
|
[FDD-LTE] Maximum download speed: 112.5Mbps / Maximum upload speed: 37.5Mbps [AXGP] Maximum download speed: 110Mbps / Maximum upload speed: 10Mbps |
| Supported frequencies Supported Frequency Bands
|
[4G] 900MHz・1.7GHz・2.1GHz・2.5GHz [3G] 900MHz, 2.1GHz |
| VoLTE (HD+) / VoLTE / HD Voice (3G) High quality voice communication possible
|
- / ● / ● |
| Massive MIMO support | ● |
| size The diagonal length of the display screen
|
5.0 inches |
|---|---|
| Display method Display method
|
TFT |
| resolution Display screen detail (horizontal x vertical)
|
720 x 1,280 pixels (HD) |
| Effective pixels Number of pixels used when shooting
|
［メイン］約800万画素 ［サブ］約200万画素 |
|---|---|
| Recorded pixels (still images) Maximum size of still image that can be captured
|
3,264 x 2,448 pixels |
| Recorded pixels (video) Maximum video size that can be recorded
|
1,920 x 1,080 pixels |
| Photo Light Auxiliary light function for shooting in dimly lit places
|
● |
| Autofocus Auto-detect focus function
|
● |
| Image stabilization (still images/videos) Reduces the effects of camera shake that can easily occur when shooting
|
● / ● |
| Camera shake reduction Reduces the effects of camera shake that can easily occur when shooting
|
－ |
| Wi-Fi tethering function (maximum number of connections) Use your smartphone or tablet as a Wi-Fi router (maximum number of devices that can be connected simultaneously)
|
● (10 units) |
|---|
| Y!mobile email (@yahoo.ne.jp) Unlimited carrier email available on multiple devices
|
● |
|---|---|
| MMS *4
It is possible to decorate text and send and receive multimedia such as audio and video.
|
● (@ymobile.ne.jp) *Available on Android™ app |
| SMS (Short Message Service) Compact emails of up to 70 full-width characters can be sent and received to smartphones and mobile phones of other companies.
|
● |
| Mobile Wallet® Smartphones can be used as electronic money
|
－ |
|---|---|
| NFC You can use linked services just by holding your smartphone over compatible devices such as home appliances.
|
－ |
| Waterproof/dustproof Compatible waterproof and dustproof standards
|
IPX5/IPX7/IP5X *5 |
| tv set Ability to watch terrestrial digital broadcasts on mobile devices
|
－ |
| Wireless LAN Wireless communication IEEE802.11 compatible standard
|
b/g/n |
| Bluetooth® It can be connected wirelessly to compatible devices such as wireless headphones and computers.
|
● (Ver.4.1) |
| Infrared communication Compatible devices can wirelessly exchange data such as phone numbers
|
● |
| GPS Use the navigation system to check your current location
|
● |
| Emergency Alert Email Earthquake and tsunami alerts can be received free of charge
|
● |
| International Roaming You can use your smartphone overseas as is.
|
● |
| Fingerprint authentication You can unlock the screen with the fingerprint sensor
|
－ |
| Accessories *6
Items included with the purchase (excluding instruction manual and warranty documents)
|
●SD card (sample) |
|---|
| release date | June 10, 2016 |
|---|---|
| Manufacturer | Kyocera Corporation |
This product [DIGNO E 503KC] complies with the government-established technical standards regarding the human absorption of radio waves and international guidelines for radio wave protection.
See here for details| Quickstart | |
|---|---|
| PDF版（約5.19MB） | download |
| Requests and Cautions | |
|---|---|
| PDF版（約8.99MB） | download |
| User Guide | |
|---|---|
| HTML version | Learn more |
| PDF版（約19.3MB） | download |
It is equipped with overheating protection, overvoltage protection, and overcurrent protection functions.
| microUSB fast charging AC adapter *1 |
Y1-AC12-HDQC |
|---|---|
| microUSB charging AC adapter 1.0A |
Y1-AC13-HDMU |
*1 Normal charging is supported. (Quick charging is not supported.)
This product has been designed to comply with the technical standards *1 set by the government regarding the human absorption of radio waves, as well as the radio wave protection limits recommended by equivalent international guidelines. These international guidelines were established by the International Commission on Non-Ionizing Radiation Protection (ICNIRP), which is in collaboration with the World Health Organization (WHO), and the limits include a sufficient safety margin for all users, regardless of their age or health condition.
National technical standards and international guidelines define the permissible value for radio wave protection as the Specific Absorption Rate (SAR), which represents the average amount of radio wave energy absorbed by the human body, and the permissible SAR value for mobile phones is 2.0 W/kg.
The maximum SAR value for this product [DIGNO E 503KC] at the side of the head is 0.565W/kg, and the maximum SAR value when worn on the body *2 is 0.354W/kg *3. Although there may be slight differences in SAR depending on the individual product, all of them meet the allowable value. Mobile phones are designed to have the minimum transmission power required for communication with mobile phone base stations, so when actually making a call, the SAR value is usually smaller. In general, the closer the distance from the base station, the lower the output of the mobile phone.
The World Health Organization has stated that "Numerous studies have been conducted over the past 20 years to assess whether mobile phones pose a potential health risk. To date, no adverse health effects have been established as being caused by mobile phone use."
For more detailed information, please refer to the following website.
World Health Organization website
For more detailed information about SAR, please refer to the following website.
