Battery capacity
3,000mAh
Maximum download speed
838Mbps
In addition to "Carrier Aggregation," a technology that enables large-volume data communication by bundling multiple different frequency bands into one, "4x4 MIMO" and "256QAM" achieve a maximum download speed of 838Mbps *1. In addition, "Massive MIMO" is supported, allowing for comfortable communication even in crowded areas. In addition, it is easy to use with simple connection via QR code, and the power-saving design allows for approximately 10 hours of battery life, so you can rest assured.
Massive MIMO support. With a large number of antennas and beamforming technology, you can enjoy comfortable mobile communications even in crowded areas. By assigning dedicated radio waves to each individual, you can achieve comfortable mobile communications even in crowded places such as stations and downtown areas where communication speeds tend to be slow.
Power-saving design with approximately 10 hours of battery life
| size Width x height x thickness of main body excluding protrusions
|
約W128.4×H65.6×D13.8mm |
|---|---|
| Weight Weight with battery pack installed
|
約145g |
| Continuous communication time *1
Communication time when radio signals are received normally (measured according to our company standards)
|
Approximately 8 hours (when power saving setting is OFF) Approximately 10 hours (when power saving setting is ON) * When carrier aggregation is not applied |
| Continuous standby time *1 (When wireless LAN is OFF) Standby time when signal reception is normal
|
Approximately 900 hours |
| Battery capacity Battery capacity, which is an indication of continuous usable time, etc.
|
3,000mAh |
| Wireless LAN Wireless communication IEEE802.11 compatible standard
|
a/b/g/n/ac |
| Wi-Fi enabled devices Number of devices that can be connected simultaneously Maximum number of Wi-Fi compatible devices that can be connected simultaneously
|
16 units *7 |
| PC connection interface Standards for connecting to a PC
|
Type-C |
| Supported external memory / Maximum supported capacity *2
Types and capacities of memory cards that can store images, videos, music files, etc.
|
－ |
| Data communication method Supported communication standards or methods
|
FDD-LTE / AXGP / TDD-LTE |
|---|---|
| Maximum communication speed (for "4G") *3
Maximum data communication speed in "4G" area
|
Download maximum 838Mbps / Upload maximum 46Mbps *When connected to wireless LAN, the maximum download speed is approximately 517Mbps *4 |
| Supported frequencies Supported Frequency Bands
|
Please see the PDF for details (40KB) |
| Massive MIMO support | ● |
| Windows® 11 Pro | ● |
|---|---|
| Windows® 10 | ● |
| Windows® 8.1 | ● |
| Windows® 8 | ● |
| Windows® 7 | ● |
| Windows Vista® | － |
| Mac OS X | ●10.6～10.14 |
| International Roaming You can use your current Pocket WiFi® overseas as is.
|
LTE / AXGP / 3G |
|---|---|
| Accessories *6
Items included with the purchase (excluding instruction manual and warranty documents)
|
－ |
| release date | Released on March 7, 2019 |
|---|---|
| Manufacturer | HUAWEI |
This product [Pocket WiFi® 801HW] complies with the national technical standards regarding human absorption of radio waves and international guidelines for radio wave protection.
See here for details| Quickstart | |
|---|---|
| PDF版（約2.46MB） | download |
| Requests and Cautions | |
|---|---|
| PDF版（約5.28MB） | download |
| operating instructions | |
|---|---|
| HTML version | Learn more |
| PDF版（約14.5MB） | download |
This product has been designed to comply with the technical standards *1 set by the government regarding the human absorption of radio waves, as well as the radio wave protection limits recommended by equivalent international guidelines. These international guidelines were established by the International Commission on Non-Ionizing Radiation Protection (ICNIRP), which is in collaboration with the World Health Organization (WHO), and the limits include a sufficient safety margin for all users, regardless of their age or health condition.
National technical standards and international guidelines define the permissible value for radio wave protection as the Specific Absorption Rate (SAR), which represents the average amount of radio wave energy absorbed by the human body, and the permissible SAR value for mobile phones is 2.0 W/kg.
The maximum SAR value for this product [Pocket WiFi® 801HW] when worn on the body *2 is 0.739 W/kg *3. Although there may be slight differences in SAR depending on the individual product, all of them meet the allowable value. Mobile phones are designed to have the minimum transmission power required for communication with mobile phone base stations, so when you are actually making a call, the SAR value is usually smaller. In general, the closer you are to the base station, the lower the output of the mobile phone.
The World Health Organization has stated that "Numerous studies have been conducted over the past 20 years to assess whether mobile phones pose a potential health risk. To date, no adverse health effects have been established as being caused by mobile phone use."
For more detailed information, please refer to the following website.
World Health Organization website
For more detailed information about SAR, please refer to the following website.
